This kit contains Koni Raid 88-Series front struts pre-assembled with PSR coil springs and HD strut tops, leaf springs, U-bolts, new leaf bushes and Koni Raid 90-Series rear shocks, also included is the option of PSRRAN-005 - Ford Ranger PX MK3 8/18-ON Front Shortened Link Pin or PSRRAN-006 - Ford Ranger PX MK3 8/18-ON Front Sway Bar Disconnect System.

Koni 88-Series Shock Absorber Key Features:

• Twin-tube hydraulic, oil filled
• 55mm outer body diameter
• 36mm piston with PTFE coated band
• Heat resistant viton seals
• Ideal for off road and desert situations
• Rebound adjustable and serviceable

Koni 90-Series Shock Absorber Key Features:

• Twin-tube hydraulic, oil filled
• 70mm outer body diamteter
• 42mm piston with PTFE coated band
• Hard chromed 18mm rod
• Heat resitant viton seals
• Large oil capacity for efficient heat dissipation
• Proven in the Simpson Desert, Canning Stock Route and Dakar Rally

Please be aware that all assembled struts are dispatched at a height that from our experience is set to the advertised height in the product listing. All leaf springs are manufactured to the height described with the constant load advertised on the vehicle. We cannot be held accountable for variations on vehicles and/or the variation of weights of accessories that would require further adjustments of heights once installed. Any height adjustment required to achieve the desired ride height is at the installers discretion and is at no way our responsibility.

• 2/2" lift from factory height
• Koni Raid Shock Absorbers
• Complete lift kit solution
• Suits PX Ranger MK3 ONLY
• Available with:
  • PSRRAN-005 - Ford Ranger PX MK3 8/18-ON Front Shortened Link Pin or
  • PSRRAN-006 - Ford Ranger PX MK3 8/18-ON Front Sway Bar Disconnect System
• For more travel or lift height check out other listings
• Colour of leaf spring bush kit may vary
