Description

Isuzu MU-X / D-Max DSL 12V 240A Alternator

Vehicle Compatibility:

This alternator is compatible with the following Isuzu models:

• Isuzu MU-X w/ 4JJ1-TCX DSL
• Isuzu MU-X w/ 4JJ3-TCX DSL
• Isuzu D-Max w/ 4JJ1-TCX DSL
• Isuzu D-Max w/ 4JJ3-TCX DSL

Important Notes:

• This unit features a LIN Reg function and is not interchangeable with alternators that utilize L or M regulator functions.
• *** A battery positive wiring upgrade is required for this alternator. ***

We highly recommend that this product be installed by a licensed Auto Electrician to ensure optimal performance and safety.

Specifications

Voltage: 12V

Amperage: 240A

Mount Leg ID: 55mm

C-C Mounts: 161mm

Hole ID Top: M8

Hole ID Bottom: 10mm

Shaft Size: 17mm

Pulley Type: 7PV, Clutch

Pulley Grooves: 7

Pulley Diameter: 62mm

Regulator Type: Internal

Connections Plug No: N/A

Terminals: B+, LIN

Excitation: External

Ground: Negative

SKU: BKS-240MUX

Barcode #: 9356659446074

Brand: Black Series
